• Audio system feature, 6-speaker system
• Cruise control, electronic with set and resume speed
• Defogger, rear-window electric
• Door locks, power programmable with lockout protection
• Lighting, interior with dome light, driver- and passenger-side door switch with delayed entry feature, cargo lights, door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions
• Mirror, inside rearview manual day/night
• Theft-deterrent system, vehicle, PASS-Key III

• 4-wheel drive
• GVWR, 7300 lbs. (3311 kg) (Standard on 4WD models.)
• Steering, power
• Suspension Package, Premium Smooth Ride
• Suspension, front coil-over-shock with stabilizer bar
• Suspension, rear multi-link with coil springs

• Daytime Running Lamps with automatic exterior lamp control
• Safety belts, 3-point, driver and right-front passenger
• Tire Pressure Monitoring System (does not apply to spare tire)

SKID PLATE PACKAGE

• includes front underbody shield starting behind front bumper and running to first cross-member
• protecting front underbody
• oil pan
• differential case and transfer case
• frame-mounted shields

FLOOR CONSOLE DELETE

• Deletes the floor console and associated audio equipment that is included with premium cloth high back bucket seats. All exposed floor areas will remain untrimmed

WHEELS, 4-17" X 7" (43.2 CM X 17.8 CM) STEEL

• (STD)

SEATS, FRONT BUCKET

• with (AG1) 6-way power driver and (AG2) front passenger seat adjusters
• adjustable head restraints
• (AM1) driver manual lumbar control
• floor console and rear storage pockets

COMMERCIAL PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

AUDIO SYSTEM, AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER

• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS)
• speed-compensated volume
• TheftLock and auxiliary audio input jack (STD)

TRANSMISSION, 6-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED

• with overdrive and tow/haul mode (STD)

SEATS, 2ND AND 3RD ROW VINYL

• with front cloth seats Provides vinyl second and third row seats and cloth front seats

ENGINE, VORTEC 5.3L V8 SFI FLEXFUEL

• with Active Fuel Management
• capable of running on unleaded or up to 85% ethanol (with gas-320 hp [238.6 kW] @ 5200 rpm
• 340 lb-ft of torque [459.0N-m] @ 4200 rpm
• with E85 ethanol-326 hp [243.1 kW] @ 5300 rpm
• 350 lb-ft of torque [472.5 N-m] @ 4400 rpm)
• iron block (STD)

• DIFFERENTIAL HEAVY-DUTY LOCKING REAR
• REAR AXLE 3.42 RATIO
• ONSTAR DELETE
• SKID PLATE PACKAGE includes front underbody shield starting behind front bumper and running to first cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields
• ENGINE BLOCK HEATER
• SEAT ADJUSTER PASSENGER POWER
• SEAT DELETE THIRD ROW PASSENGER
• FLOOR CONSOLE DELETE Deletes the floor console and associated audio equipment that is included with premium cloth high back bucket seats. All exposed floor areas will remain untrimmed
• WHEELS 4-17" X 7" (43.2 CM X 17.8 CM) STEEL (STD)
• LICENSE PLATE BRACKET FRONT
• LUGGAGE RACK DELETE
• SEATS FRONT BUCKET with (AG1) 6-way power driver and (AG2) front passenger seat adjusters adjustable head restraints (AM1) driver manual lumbar control floor console and rear storage pockets
• TIRES P265/70R17 ON-/OFF-ROAD BLACKWALL
• TIRE SPARE P265/70R17 ON-/OFF-ROAD BLACKWALL
• EBONY PREMIUM CLOTH SEAT TRIM
• COMMERCIAL PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• SUMMIT WHITE
• AUDIO SYSTEM AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed-compensated volume TheftLock and auxiliary audio input jack (STD)
• TRANSMISSION 6-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode (STD)
• SEATS 2ND AND 3RD ROW VINYL with front cloth seats Provides vinyl second and third row seats and cloth front seats
• ENGINE VORTEC 5.3L V8 SFI FLEXFUEL with Active Fuel Management capable of running on unleaded or up to 85% ethanol (with gas-320 hp [238.6 kW] @ 5200 rpm 340 lb-ft of torque [459.0N-m] @ 4200 rpm with E85 ethanol-326 hp [243.1 kW] @ 5300 rpm 350 lb-ft of torque [472.5 N-m] @ 4400 rpm) iron block (STD)
• Four Wheel Drive
• Tow Hitch
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Steel Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Running Boards/Side Steps
• Automatic Headlights
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• AM/FM Stereo
• CD Player
• MP3 Capability
• Auxiliary Audio Input
• Satellite Radio
• Requires Subscription
• Split Bench Seat
• Power Outlet
• Driver Adjustable Lumbar
• Pass-Through Rear Seat
• Rear Bench Seat
• Power Driver Seat
• Pass-Through Rear Seat
• Adjustable Steering Wheel
• Cruise Control
• Steering Wheel Audio Controls
• Power Windows
• Power Door Locks
• Keyless Entry
• Power Door Locks
• Cruise Control
• Immobilizer
• Multi-Zone A/C
• A/C
• A/C
• Rear A/C
• Rear Defrost
• Power Outlet
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Front Reading Lamps
• Rear Reading Lamps
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag
• Requires Subscription
• Tire Pressure Monitor

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• Fuel Economy Est-Combined (MPG): 16
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 160
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 16.8
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4100
• Curb Weight - Front (lbs): 2924
• Curb Weight - Rear (lbs): 2657
• Gross Vehicle Weight Rating Cap (lbs): 7300
• Gross Combined Wt Rating (lbs): 11500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5700
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 855
• Suspension
• Suspension Type - Front: Coil springs
• Suspension Type - Rear: Coil springs
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4100
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 4100
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 46.0
• Shock Absorber Diameter - Rear (mm): 46.0
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): 1.1
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.2
• Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.8
• Tires
• Front Tire Order Code: QJP
• Front Tire Order Code: QGI
• Rear Tire Order Code: QJP
• Rear Tire Order Code: QGI
• Spare Tire Order Code: 4JP
• Spare Tire Order Code: ZVL
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/70R17
• Spare Tire Size: P265/70R17
• Front Tire Capacity (lbs): 2134
• Rear Tire Capacity (lbs): 2134
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7.0
• Rear Wheel Size (in): 17 x 7.0
• Spare Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 17.75
• Steering Ratio (:1), At Lock: 17.75
• Turning Diameter - Curb to Curb (ft): 39.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 116.0
• Length, Overall w/rear bumper (in): 202.0
• Width, Max w/o mirrors (in): 79.0
• Height, Overall (in): 76.9
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 31.6
• Ground Clearance, Front (in): 10.5
• Ground Clearance, Rear (in): 9.1
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): - TBD -
• Cargo Area Length @ Floor to Seat 1 (in): 81.4
• Cargo Area Length @ Floor to Seat 2 (in): 49.4
• Cargo Area Length @ Floor to Seat 3 (in): 15.2
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 49.10
• Cargo Box (Area) Height (in): 41.7
• Cargo Volume to Seat 1 (ft³): 108.9
• Cargo Volume to Seat 2 (ft³): 60.3
• Cargo Volume to Seat 3 (ft³): 16.9
• Interior Dimensions
• Passenger Capacity: 8
• Passenger Capacity: 5
• Passenger Capacity: 9
• Front Head Room (in): 41.1
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.3
• Front Hip Room (in): 64.4
• Second Head Room (in): 39.2
• Second Leg Room (in): 39.0
• Second Shoulder Room (in): 65.2
• Second Hip Room (in): 60.6
• Third Head Room (in): 37.9
• Third Leg Room (in): 25.6
• Third Shoulder Room (in): 61.7
• Third Hip Room (in): 49.1
• Summary
• Vehicle Name: Chevrolet Tahoe
• Body Style: 4 Door
• Body Code: E52
• Emissions
• EPA Greenhouse Gas Score: 3
